Technical Specification
| Property |
Basic Edition |
Comfort Edition |
| Length x width x height(mm) |
451x176x1790 |
451x176x1790 |
| Wheel base (mm) |
2755 |
2755 |
| Tread (front/rear) (mm) |
1494/1492 |
1494/1492 |
| Minimum ground clearance |
170 |
170 |
| Minimum turning radius (m) |
5.25 |
5.25 |
| Curb weight (Kg) |
1338 |
1230/1270 |
| Tire Specification |
185/65 R15 |
205/60 R15 |
| Number of Seats |
8 |
7 |
| Property |
Basic Edition |
Comfort Edition |
| Engin model |
ACTECO-SQRD4G15 |
ACTECO-SQRD4G15 |
| Engine Type |
inline 4 cylinders SOHC 16V MFI engine |
inline 4 cylinders SOHC 16V MFI engine |
| Engine Displacement (cc) |
1497 |
1497 |
| Maximum Power (kw) |
80 |
80 |
| Maximum Torque (N.m) |
140 |
140 |
| Compression Ratio |
10.5:1 |
10.5:1 |
| Maximm speed (km/h) |
155 |
155 |
| Transmission type |
5MT(QR515MHF) |
5MT |
| Fuel tank capacity (L) |
45 |
45 |
| Fuel Consumption (km/l) |
15 |
15 |
| Emission Standard |
EulV |
ChinaV |
| Property |
Basic Edition |
Comfort Edition |
| Type of break system (front/rear) |
Disc/Drum |
Disc/Disc |
| Type of Suspension system (front/rear) |
McPherson Independent Suspension/Torsional beam type helical spring |
McPherson Independent Suspension/Torsional beam type helical spring |
| Wheel drive |
FF |
FF |
