Karry K50

A Division of Chery Holding

Karry K50

Technical Specification

Property Basic Edition Comfort Edition
Length x width x height(mm) 451x176x1790 451x176x1790
Wheel base (mm) 2755 2755
Tread (front/rear) (mm) 1494/1492 1494/1492
Minimum ground clearance 170 170
Minimum turning radius (m) 5.25 5.25
Curb weight (Kg) 1338 1230/1270
Tire Specification 185/65 R15 205/60 R15
Number of Seats 8 7
Property Basic Edition Comfort Edition
Engin model ACTECO-SQRD4G15 ACTECO-SQRD4G15
Engine Type inline 4 cylinders SOHC 16V MFI engine inline 4 cylinders SOHC 16V MFI engine
Engine Displacement (cc) 1497 1497
Maximum Power (kw) 80 80
Maximum Torque  (N.m) 140 140
Compression Ratio 10.5:1 10.5:1
Maximm speed (km/h) 155 155
Transmission type 5MT(QR515MHF) 5MT
Fuel tank capacity (L) 45 45
Fuel Consumption (km/l) 15  15
Emission Standard EulV ChinaV
Property Basic Edition Comfort Edition
Type of break system (front/rear) Disc/Drum Disc/Disc
Type of Suspension system (front/rear) McPherson Independent Suspension/Torsional beam type helical spring McPherson Independent Suspension/Torsional beam type helical spring
Wheel drive FF FF
.
